Ceramic PP 5/8 Inch Cooling Tower Packing Metal Pall Ring

Metal Stainless Steel Ceramic PP Tower Packing Cooling Tower Pall Ring

Product description

"Hualai packaging mall" metal ball ring takes advantage of the circular characteristics of mass transfer and the saddle shape with low pressure drop, which has high load and low pressure drop, good gas-liquid distribution and high mass transfer efficiency. It has mechanical stability and small crushing probability, and is suitable for deep formations.

The metal ball ring has the characteristics of thin wall, heat resistance, large free volume, large capacity, low resistance and high separation efficiency.

It is especially suitable for vacuum distillation column to deal with heat sensitive, decomposable and polymerizable systems.

Material: carbon steel. SS304, 304L, 410, 316, 316L, etc.

Bauer ring application:

It is widely used in packed towers in petrochemical, chemical fertilizer, environmental protection and other industries (such as isolation, absorption, distillation, desorption, ordinary pressure reducing devices)

Advantages of metal ball ring:

High scale resistance; A variety of materials are available; High temperature application; ü the machine is solid and the probability of damage is small; Good liquid / gas distribution and high mass transfer efficiency.

Metal Pall Ring specification data groups:

50mm Pall Rings
Free Space (%)	96
Specific Surface Area (m2/m3) 100
No. Per Unit Volume (m3 )	6,000
Packing Factor (m-1)	107
Specific Weight (kg/m3) 196 – 354 Stainless Steel
Dimensions (mm)	50 x 50
Thickness (mm)	0.5 – 0.9
Normal Material stainless steel 304, 316L

16mm Pall Rings
Free Space (%)	93
Specific Surface Area (m2/m3) 316
No. Per Unit Volume (m3 )	210,000
Packing Factor (m-1)	315
Specific Weight (kg/m3) 400 – 535 Stainless Steel
Dimensions (mm)	16 x 16
Thickness (mm)	0.3 – 0.4
Normal Material stainless steel 304, 316L

25mm Pall Rings
Free Space (%)	94
Specific Surface Area (m2/m3) 209
No. Per Unit Volume (m3 )	49,500
Packing Factor (m-1)	176
Specific Weight (kg/m3) 322 – 644 Stainless Steel
Dimensions (mm)	25 x 25
Thickness (mm)	0.4 – 0.8

38mm Pall Rings
Free Space (%)	95
Specific Surface Area (m2/m3) 122
No. Per Unit Volume (m3 )	13,450
Packing Factor (m-1)	107
Specific Weight (kg/m3) 200 – 400 Stainless Steel
Dimensions (mm)	38 x 38
Thickness (mm)	0.4 – 0.8
Normal Material stainless steel 304, 316L
