Detail Information

Product Name:	Liquid Distributor	Material:	Stainless Steel 316
Shape:	Mesh Corrugated	Thickness:	100mm, 150mm, Or As Per Order
Marketing Type:	Ordinary Product	Type:	Packed Column Internals
Shape & Size:	Φ1700-Φ630 Φ2200-Φ820	Surface Area:	250㎡/m3,500㎡/m3,700㎡/m3
Application:	Retail, Construction Works , Packed Column	Key Selling Points:	Liquid Distribution
High Light:	SS304 Pan Type random tower packing , 3mm Thick random packing column internals , SS304 random packing column internals

Product Description

3mm Thick Liquid Controls Distributors Ss304 Random Packing Tower Internals Pan Type

Description

Product:	Trough Liquid Distributor	Advantage:	Uniform Distribution
Design Service:	Customization	Flow Rate:	As Per Requirement
Application:	Packing Tower	Material:	Stainless Steel, Or As Per Order
Type:	Gravity Type	Plate Thickness:	3mm, 4 Mm, 5 Mm, 6 Mm, And Others
Size:	Any Size	Position:	On Top Of Packing
High Light:	ss 304 liquid distributor , ss 304 liquid controls distributors , pan type liquid controls distributors

SS304 Random Packing Tower Internals Pan Type Liquid Distributor

1. Trough liquid distributor introduction,

Liquid distributor is the most important column internal from a process point of view. It is required to distribute liquid uniformly at the top of packing tower. Meanwhile a liquid distributor must have sufficient gas passage area to avoid high pressure drop or liquid entrainment.

2. Choice of Tail gas scrubber tower interal water distributor:

Column diameter inches	System fouling tendency	Specific liquid load gpm/ft²	Suitable type of liquid distributor
＜48	Low / medium / high	1 - 30	Pan type liquid distributor
＞12	Low / medium	0.8 - 50	Deck type liquid distributor with long risers
＞36	Low / medium / high	2 - 40	Weir trough type liquid distributor
＞20	low	1.5 - 10	Pipe arm type liquid distributor
all	high	0.2 - 50	Spray type liquid distributor

3. How to choose liquid distributor?

Liquid distributor is the most important column internal from a process point of view. It is required to distribute liquid uniformly at the top of packing tower. Meanwhile a liquid distributor must have sufficient gas passage area to avoid high pressure drop or liquid entrainment.
Characteristics of an ideal liquid distributor:
Uniform liquid distribution; Resistance to fouling; Proper trundown capabitity;Low gas pressure drop; Minimum height; Higher cross-mixing capabity.
When we need to select a liquid distributor, we need to consider the tower diameter, flow rate, turndown ratio, available height (in case of revamp) and fouling resistance.
Weir type gravity distributor:
Generally speaking, the weir type gravity distributor is one of the least troublesome distributors. It has excellent trundown capability and can handle large liquid load. However it can usually provide only a limited number of drip points (minimum 30 number of weirs per m2). It is also extremely sensitive to levelness and liquid surface agitation.

4. Characteristics of custom made water distributor:

Liquid distributor is the most important column internal from a process point of view. It is required to distribute liquid uniformly at the top of packing tower. Meanwhile a liquid distributor must have sufficient gas passage area to avoid high pressure drop or liquid entrainment.

Uniform liquid distribution; Resistance to fouling; Proper trundown capabitity;Low gas pressure drop; Minimum height; Higher cross-mixing capabity.

Tower Internals Advantage

1.Make the liquid distributor from multipoint into infinite point. The distribution uniformity has an impressive promotion. Make the line distribution and surface diatribution come true.
2. Eakage blocking design.
3. Simple construction, Lower placeholder, Light weight, Easy installation.

Welcome your inquiryStructured Packing specifications.

What types of liquid distributor for choice?

The liquid distributor has various types according to different standard and using conditions. Overall, it has four types.

* Spray nozzles. Hemispherical spray nozzle will distribute the liquids evenly to the random or structured packing bed. There are numerous small holes in 3–10 mm on the nozzle. It is suitable for the smaller diameter packed tower, which is smaller than 600mm.

* Perforated pipe distributor. Single row or double row perforated pipes will evenly distributed the liquid to the packing bed through perforated holes under the pipe. It is widely used in the medium liquid, reduced pressure distillation towers and wire gauze structured packing towers. It can be made into ladder shapes and ring shapes.

* Through distributor. It has through type and through-pan type, which is widely used in the heavy liquid and gas load, high viscosity liquid and liquid with suspended solid.

* Orifice distributor. It can be divided into perforated plate type and pan type. The liquid will flow down through perforated holes or overflow from the annulus between the distributor and the vessel. It is suitable for the small diameter tower, which is smaller than the 800 mm.

Tag:

Place of Origin:	Anping, China
Brand Name:	Yuanqiao
Certification:	ISO9001
Model Number:	YQ-103

Minimum Order Quantity:	1pc
Price:	Negociation
Packaging Details:	Wooden boxes
Delivery Time:	5-10 days
Payment Terms:	L/C, T/T
Supply Ability:	1000 pcs per month
