Donut Circle Shape Teflong 580mm Diameter Wire Mesh Demister For Scrubber

Basic Information
Place of Origin: Anping, China
Brand Name: Yuanqiao
Certification: ISO9001
Model Number: YQ-355
Minimum Order Quantity: 1pc
Price: Negociation
Packaging Details: Wooden boxes or pallet
Delivery Time: 5-10 days
Payment Terms: L/C, T/T
Supply Ability: 1000 pcs per month
Detail Information
Product Name: Mesh Pad Demister Material: Teflong
Thickness: 100mm, 150mm, Or As Per Order Shape: Donut, Circle
Sections: 6/8, Or As Per Order Application: Scrubber
Grids: 25*3mm Flat Bar Shape & Size: Φ1700-Φ630 Φ2200-Φ820
Factory Name: Yuanqiao Application: Filter
High Light:

580mm wire mesh demister

,

Teflong wire mesh demister

,

580mm mesh pad demister


Product Description

Donut Circle Shape Teflong 580mm Diameter Wire Mesh Pad Demister

Donut Circle Shape Teflong 580mm Diameter Wire Mesh Pad Demister





Demister Inquiry Table if Calculation Suggestions and Service are needed



Demister / mist eliminator DATA



Operating data
Gas Max. gas volume flow (operating conditions) M3/h
Gas density (operating condistions) Kg/m3
Operating pressure Bar (a)
Operating temperature
Liquid Liquid content Kg/h
Liquid density Kg/m3
Dynamic viscosity of the liquid mPas
Geometrical data
Flow direction Horizontal ¨
Vertical ¨
Installed in Column ¨
Pipe ¨
Column diameter or dimensions mm
Opening for installation Manhole ¨ DN
Vessel flange ¨ Size
Requirements
type of mist eliminator Wire mesh demister
Material
Efficiency of separation %
Max. pressure drop
Miscellaneous



Please pay attention to the Unit when refering to this sheet.



DEMISTER Use :



1: Knockout drums and separators – save on capital costs by decreasing vessel size-recover costly fatty acids from stream-reduce compressor maintenance by preventing scale build-up.



2: Absorbers – reduce overhead losses of glycols in dehydrators to no more than 0.1 gal/MMSCF natural gas-cut losses of absorption oil and amines in CO2 systems.



3: Scrubbers – reduce chemical discharges from Kraft mill smelt dissolver tank to less than 0.11 kg/dry ton (0.25 lb/dry ton) of pulp-improve scrubber efficiency by removing particulates carried in entrained liquids.



4: Distillation columns – improve product purities and increase throughput capacities for petrochemicals, organic intermediates, fine chemicals.



5: Evaporators – prevent carryover loss of valuable products, keep condensate TDS <10 ppm for highest quality boiler feed water-clean up vacuum ejector stream discharge-lower maintenance in vapor re-compression systems.



6: High pressure steam systems – provide dry steam- cut TDS to <10 ppb in condensate-eliminate build-up on turbine blades.



7: Refinery towers – increase throughput capacity-take deeper cuts for greater product yields – prolong catalyst life in downstream cracking and reforming units by reducing carbon and metals in side draws-use lower grade crudes.






Yuanqiao Team is ready to help with what you need. Welcome your inquiry to Hualai!



Donut Circle Shape Teflong 580mm Diameter Wire Mesh Demister For Scrubber 0



Donut Circle Shape Teflong 580mm Diameter Wire Mesh Demister For Scrubber 1
